SPD-20-240P | MEAN WELL SURGE PROTECTOR 240VAC 20KA

SKU: SPD-20-240P

Availability:

3 in stock


3 in stock

Quantity Price Per Unit
1+ 18.00 Excl GST
Operating Voltage: 240 VAC   50/60 Hz
MCOV: 300 VAC
Voltage Protection Rating: 1500 V (L-FG, N-FG, L-N)
Voltage Protection Level: 1500 V (L-PE, N-PE, L-N)
Nominal Discharge Current: 5 kA
Max Surge Current (8/20us): 20 kA
Max. Discharge current: 20 kA
Short Circuit Current Rating: 5 kA
Short-Circuit Withstand: 1.5 kVA
Response Time: < 25ns
Withstand: 1600 VAC / 1 min
Operating Temperature: -40 ~ +70°C
 Dimensions:  90 x 70 x 50 mm
