The Mean Well SDR-75-24 is a slim line 76.8W 24VDC Din Rail power supply. The design of the SDR-75-24 body has been kept as small as possible to allow for maximum space inside of the cabinets it is being installed into. With working efficiency up to 91%, the entire SDR series can operate at the ambient temperature of -25⁰ and 70⁰ under air convection.
Din Rail | Mean Well | Power Supplies
SDR-75-24 | Mean Well DIN Rail 75W 24VDC 3.2A
SKU: SDR-75-24
Availability:
5 in stock (can be backordered)
Slim & High Efficiency
Contact us or Register for Trade, Wholesale/ Reseller Pricing.
$73.00 Exc GST
| Qty | Price Per Unit | Total Price |
| 1+ | $80.30 Incl GST $73.00 Excl GST | $80.30 Incl GST $73.00 Excl GST |
| 10+ | $77.77 Incl GST $70.70 Excl GST | $777.70 Incl GST $707.00 Excl GST |
SKU : SDR-75-24
Categories : Din Rail > Mean Well > Power Supplies
Tags : Din Rail, LED Driver, Mean Well, Power Supply
| Output Type: | Constant Voltage |
| Output Channels: | Single |
| Output Voltage: | 24 VDC |
| Output Current: | 3.2 A |
| Output Wattage: | 76.8 W |
| Input Voltage: | 88 ∼ 264 VAC |
| Connection In: | Screw DIN Terminals |
| Connection Out: | Screw DIN Terminals |
| Case Type: | Metal Enclosed |
| Dimensions: | 32 x 126 x 102 mm |
| IP Rating: | None |
| Warranty: | 3 Years |
| Additional Features | |
| DC OK Indicator: | Yes |
| Voltage Adjustment: | 24 ∼ 28V |
| Current Adjustment: | None |
| Cooling Fan: | No |
