MDR-20-12 | MEAN WELL DIN RAIL 20W 12VDC 1.67A

SKU: MDR-20-12

Availability:

6 in stock (can be backordered)


Ultra Slim

6 in stock (can be backordered)

Quantity Price Per Unit
1+ 27.90 Excl GST

The Mean Well MDR-20-12 is a slim line 20W 12VDC Din Rail power supply. The design of the MDR-20-12 body has been kept as small as possible to allow for maximum space inside of the cabinets it is being installed into. The entire MDR series adopts a full AC input range from 85VAC to 264VAC.

MDR-20-12 Data Sheet

Output Type: Constant Voltage
Output Channels: Single
Output Voltage: 12 VDC
Output Current: 1.67 A
Output Wattage: 20 W
Input Voltage: 85 ∼ 264 VAC
Connection In: Screw DIN Terminals
Connection Out: Screw DIN Terminals
Case Type: Plastic Enclosed
Dimensions: 23 x 90 x 100 mm
IP Rating: None
Warranty: 3 Years

Additional Features
DC OK Indicator: Yes
Voltage Adjustment: ± 10%
Current Adjustment: None
Cooling Fan: No

MDR-20-12 Data Sheet
