Smart Electronic Components Procurement
75W 12V DC LED Driver
| | | | |

LIFUD 75W 12VDC 6.25A ADJUSTABLE IP67 LED DRIVER

SKU: LF-GOE075YV012A

Availability:

297 in stock (can be backordered)

  • 75W 12VDC 6.25A
  • Output Voltage Adjustable 92%-108%
  • Flicker Free
  • IP67
  • 5 Year Warranty

Enclosed metal case constant voltage power supply.

Contact us or Register for Trade, Wholesale/ Reseller Pricing.

$55.50 Exc GST

Qty Price Per Unit Total Price
1+ $61.05 Incl GST $55.50 Excl GST $61.05 Incl GST $55.50 Excl GST
10+ $58.03 Incl GST $52.75 Excl GST $580.25 Incl GST $527.50 Excl GST

Lifud LF-GOE075YV012A | 75W 12V DC LED Driver

The Lifud LF-GOE075YV012A is a high-quality, 75W 12V DC LED driver designed for reliable and efficient 12V DC power delivery to LED lighting systems. With its robust performance and safety certifications, this driver is ideal for both indoor and outdoor lighting applications.

Key Features:

  • High Efficiency: Operates with up to 88% efficiency, ensuring minimal energy loss and heat generation.
  • Constant 12V Output: Provides a stable 12V DC output, ideal for powering low-voltage LED lighting systems.
  • Wide Input Range: Supports a universal AC input of 100-277V, suitable for global use in various environments.
  • Durable Build: IP67-rated for dust and water resistance, making it perfect for outdoor installations in harsh conditions.
  • Low THD: Ensures low Total Harmonic Distortion (THD) for cleaner power and better performance.
  • Compact Design: Slim, compact housing for easy installation in tight spaces.
  • Advanced Protections: Includes protections against short circuit, overvoltage, overcurrent, and over-temperature for enhanced safety.
  • Certified Safety Standards: Complies with UL, CE, and TUV certifications, ensuring reliable and safe operation across diverse applications.
  • 5-Year Warranty: Backed by Lifud’s comprehensive 5-year warranty, offering long-term reliability and peace of mind.

The LF-GOE075YV012A from RMS Components is the perfect choice for energy-efficient, low-voltage LED lighting systems in commercial, residential, and outdoor applications.

Applications:

  • LED Strip Lighting
  • LED Signage
  • Outdoor Lighting Systems
  • Commercial and Residential Lighting

As authorised distributors of Lifud products, we offer 100% original items directly from the factory, with no rebranding involved. This product is equivalent to: SAL PLUTO 75/12V/FC

LF-GOE075YV012A Data Sheet

SKU : LF-GOE075YV012A

Categories : Constant Voltage LED Drivers > Indoor LED Drivers > LED Drivers > Lifud > Power Supplies > Weatherproof LED Drivers

Tags : 12VDC, 6.25A, 75W, Adjustable, IP67, LED Driver, Lifud, Power Supply

Output Type: Constant Voltage
Output Voltage: 12 VDC
Output Current: 6.25 A
Output Wattage: 75 W
Input Voltage: 100 – 277 VAC (max 305VAC)
Input Current: 0.85A (max)
Connection In: Mains Plug & Flex
Connection Out: Sheathed Cable 250mm 1.8m
Case Type: Metal Enclosed
Flicker Percentage: ≤1%
Efficiency: ≥87% / 230VAC @ full load
Power Factor: ≥0.95 / 230VAC @ full load
Working Temp: -40°C ~ +60°C
Dimensions: 169.4 x 61 x 34 mm
IP Rating: IP67
Warranty:  5 Years (Tc ≤75°C)
Protections: Over Voltage: ≤16V (output voltage turns off-auto-recovery)
  Over Current: ≤150% (auto-recovery)
  Short Circuit: Hiccup mode (auto-recovery)
  Surge: L-N: 6KV; L/N-GND: 8KV
Additional Features
Dimmable: No
Voltage Adjustment: Yes (11.04~12.96VDC) (92~108%)
Current Adjustment: None
Cooling Fan: No

LF-GOE075YV012A Data Sheet

This product is covered by a five year manufacturer’s warranty against damaged caused by normal use and operation or product defects. All warranty claims are “return to base” which requires the customer to return the goods (at their cost) back to the supplier for evaluation.

If found to be faulty, RMS Components will repair the product, replace the product, or refund the cost of the goods at it’s discretion, and ship back to the customer.
