5 Channel LED Amplifier
Enhance the performance of your LED strip lighting setup with this 5 Channel LED Amplifier, designed to extend signal range and power output across multi-channel RGB+CCT installations. Ideal for use with RGB, RGBW, and RGB+CCT LED strips, this amplifier ensures consistent brightness and colour across longer runs or multiple strip segments.
Operating on a wide input voltage range of 12–24VDC, it delivers up to 6A per channel and a combined maximum output of 15A. Its high-speed 10Mbps switching rate ensures smooth and responsive signal replication without delay or flicker.
This amplifier operates using a common anode configuration, making it compatible with most LED strip configurations. It’s perfect for both commercial and residential lighting projects requiring strong, reliable signal amplification over extended distances.
Specifications:
-
Input voltage: 12–24VDC
-
Output voltage: 12–24VDC
-
Output current: 6A per channel
-
Max total output: 15A
-
Switching rate: 10Mbps
-
Connection type: Common anode
-
Operating temperature: -20°C to 60°C
Features:
-
Boosts signal and power for RGB+CCT LED strip installations
-
Supports up to 5 channels for multi-colour control
-
Smooth, high-speed switching
-
Extends the length and consistency of your lighting system
-
Compatible with 12V and 24V LED systems
-
Durable and efficient for both indoor and outdoor projects
