MDR-40-5 | MEAN WELL DIN RAIL 30W 5VDC 6A

SKU: MDR-40-5

Availability:

Available on backorder


Ultra Slim

Available on backorder

Quantity Price Per Unit
1+ 34.90 Excl GST

The Mean Well MDR-40-5 is a slim line 30W 5VDC Din Rail power supply. The design of the MDR-40-5 body has been kept as small as possible to allow for maximum space inside of the cabinets it is being installed into. The entire MDR series adopts a full AC input range from 85VAC to 264VAC.

MDR-40-5 Data Sheet

SKU: MDR-40-5 Categories: , , Tags: , ,
Output Type: Constant Voltage
Output Channels: Single
Output Voltage: 5 VDC
Output Current: 6.0 A
Output Wattage: 30 W
Input Voltage: 85 ∼ 264 VAC
Connection In: Screw DIN Terminals
Connection Out: Screw DIN Terminals
Case Type: Plastic Enclosed
Dimensions: 40 x 90 x 100 mm
IP Rating: None
Warranty: 3 Years

Additional Features
DC OK Indicator: Yes
Voltage Adjustment: 0 ∼ +20%
Current Adjustment: None
Cooling Fan: No

MDR-40-5 Data Sheet
