MDR-10-24 | MEAN WELL DIN RAIL 10W 24VDC 0.42A

SKU: MDR-10-24

Availability:

Available on backorder


Available on backorder

Quantity Price Per Unit
1+ $26.29 Incl GST $23.90 Excl GST

The Mean Well MDR-10-24 is a slim line 10W 24VDC Din Rail power supply. The design of the MDR-10-24 body has been kept as small as possible to allow for maximum space inside of the cabinets it is being installed into. The entire MDR series adopts a full AC input range from 85VAC to 264VAC.

MDR-10-24 Data Sheet

Output Type: Constant Voltage
Output Channels: Single
Output Voltage: 24 VDC
Output Current: 0.42 A
Output Wattage: 10 W
Input Voltage: 85 ∼ 264 VAC
Connection In: Screw DIN Terminals
Connection Out: Screw DIN Terminals
Case Type: Plastic Enclosed
Dimensions: 22.5 x 90 x 100 mm
IP Rating: None
Warranty: 3 Years

Additional Features
DC OK Indicator: Yes
Voltage Adjustment: No
Current Adjustment: None
Cooling Fan: No
